6-layer fr4 pcb board TWS Bluetooth impedance circuit pcb board batch pcb
US$ 5
1–999 Piece
US$ 0.5
1000–4999 Pieces
US$ 0.4
5000–9999 Pieces
US$ 0.3
10000–49999 Pieces
US$ 0.1
≥50000 Pieces
Product Attribute
Management Certification:
ISO, IATF 16949
Product Certification:
ROHS, UL, CE, REACH
Application:
Electronic Device, Communication, OEM Electronic, Repair, Household, Car, Home, Industrial, Automotive
Lead Time: 5 – 7 Days
Business Type: , Exporter, Online Seller, Distributor, Trading Company, Manufacturer
High
Response Rate
≤24 h
Response Time
700 to 749
Employees
Company/product Brochure
7124.13 KB
Visit Store
Follow
Product Certifications
REACH
From 2024/11/28
UL
From 2023/06/13
Product information
E-commerce ERP componentized flexible printed circuit boards handheld terminal data collector main fpc board pcb file
PCBgate Group company introduction
4-layer impedance-selective board (surface treatment: immersion gold + OSP)
Halogen-free board; board thickness 0.8mm;
Minimum hole size 0.15mm;
Minimum trace width/spacing 3mil/3mil, minimum solder mask bridge 3mil
--Written by Miya-250826
PCB Manufacturing Capacity
| Item | Specification |
| Material | FR-4, FR1,FR2, CEM-1,CEM-3; Rogers,Teflon,Arlon; Aluminum Base, Copper Base,Ceramic ,etc. |
| Remarks | High Tg CCL is Available(Tg>=180℃) |
| Finish Board Thickness | 0.2 mm~6.00mm(8mil-126mil) |
| Surface Finish | Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um) |
| Shape | Routing、Punch、V-cut、Chamfer |
| Surface Treatment | Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA) |
| Silkscreen(black, yellow, white) | |
| Peel able-mask(red, blue, thickness>=300um) | |
| Minimum Core | 0.075mm(3mil) |
| Copper Thickness | 1/2 oz min; 12oz max |
| Min Trace Width & Line Spacing | 0.075mm/0.075mm(3mil/3mil) |
| Min Hole Diameter for CNC Drilling | 0.1mm(4mil) |
| Min Hole Diameter for Punching | 0.6mm(35mil) |
| Biggest panel size | 2000mm * 700mm |
| Hole Position | +/-0.075mm(3mil) CNC Drilling |
| Conductor Width(W) | +/-0.05mm(2mil) or +/-20% of original |
| Hole Diameter(H) | PTHL:+/-0.075mm(3mil) |
| Non PTHL:+/-0.05mm(2mil) | |
| Outline Tolerance | +/-0.1mm(4mil) CNC Routing |
| Warp & Twist | 0.70% |
| Insulation Resistance | 10Kohm-20Mohm |
| Conductivity | <50ohm |
| Test Voltage | 10-300V |
| Panel Size | 110 x 100mm(min) |
| 2000 x 700mm(max) | |
| Layer-layer misregistration | 4 layers:0.15mm(6mil)max |
| 6 layers:0.25mm(10mil)max | |
| Min spacing between hole edge to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Min spacing between board outline to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Board thickness tolerance | 4 layers:+/-0.13mm(5mil) |
Flexible PCB Capacity
| FPC Tech Specification | |
| Items | Capabilities |
| Layers | FPC:1 to 6 Layers, Rigid Flex: 2 to 10 Layers |
| Regular Base Materials | Kapton,Polyimide(PI), Polyester(PET) |
| Base Copper Thickness | 1/3 oz to 8oz |
| Regular Base Material Thickness | 12.5um to 50um(FPC) |
| 0.1mm to 3.2mm(Rigid) | |
| Regular Coverlay Thickness | 27um to 50um |
| Regular Adhesive Thickness | 12um to 25um |
| Blind or Buried Vias | Yes |
| Impedance Control | Yes |
| Min.Line Width/Spacing | 0.04mm/0.04mm |
| Surface Finishing | Electroplate Ni/Au(Flash gold/Soft gold/Hard gold), ENIG, HASL, Immersion Tin,OSP |
| Outline Fabrication | Die cut, laser cut, CNC routing, V-scoring |
| Hole to edge(Hard tool/Die Cut) | ±0.1/±0.2mm |
| Edge to edge(Hard tool/Die Cut) | ±0.05/±0.2mm |
| Circuit to edge(Hard tool/Die Cut) | ±0.07/±0.2mm |
Shipping Information
| FOB Port Shenzhen | Lead Time 7–15 days |
|---|---|
| Weight per Unit 1.0 Kilograms | Dimensions per Unit 7.2 x 3.2 x 0.06 Centimeters |
| HTS Code 8517.79.90 00 | Units per Export Carton 36.0 |
| Export Carton Dimensions L/W/H 58.0 x 26.0 x 36.0 Centimeters | Export Carton Weight 0.1 Kilograms |
Contact us:
Email: sales@pcbgate888.com; bluesky@xdpcba.com
Skype: zenglixia666
Mobile/WeChat/WhatsApp: +86 15919476409
Website: www.pcbgate888.com
Main Export Markets
- North America
- Western Europe
- Asia
- Australasia
- Central/South America
- Eastern Europe
- Mid East/Africa
- Russia; Norway
Download more information about this product
Technical Specification
68.35kb
Shipping Information
- FOB Port: Shenzhen
- Lead Time: 5–7 Days
- Weight Per Unit: 10.0 Grams
- Dimensions Per Unit: 10.0 x 5.0 x 0.16 Centimeters
- US HTS Code: 8534.00.90 00
- Units per Export Carton: 5000.0
- Export Carton Dimensions: 44.0 x 30.0 x 34.0 Centimeters
- Export Carton Weight: 5.0 Kilograms
Main Export Markets
- - Western Europe
- - North America
- - Eastern Europe
- - Mid East/Africa
- - Central/South America
- - Australasia
- - Asia
